Mini crane GB 150
Electric crane for handling molds in the tire production sector.
The GB 150 is the crane for handling molds, ideal for use in the tire production sector.
The reduced dimensions of the GT cranes electric cranes allow an agile handling in internal spaces such as industrial ones.
Load capacity up to 150 kg (330 lbs).
Technical features
| Features | Serie GB 150 |
|---|---|
| Maximum load capacity | 150 Kg/ 330 lbs |
| Standard min. hook’s height from the ground | 500 mm |
| Standard max. hook’s height from the ground | 2.600 mm |
| Possibility to extend height up to (option) | – |
| Standard max. telescopic extension | 1.500 mm |
| Capacity at standard max. telescopic extension | 150 Kg/ 330 lbs |
| Possibility to extend telecopic extension up to (option) | – |
| Capacity at max.telescopic extension (point 7) | – |
| Rotation (option) | – |
| Wheelbase | 1.000 mm |
| Dimensions- lenght | 1.560 mm |
| Dimensions- width | 820 mm |
| Dimensions- height | 1.470 mm |
| Adjustable speed from / to | From 0 to 40 m/min |
| Max. surmountable slope ( unloaded ) | 8% |
| Max. surmountable slope ( loaded ) | 3% |
| Front wheels | 4 x Ø 160 x 60 mm |
| Rear driving wheel | – |
| Wheels material | Polyurethane |
| Drive | – |
| Total weight: | 525 Kg/ 1157 lbs |
| Electric motor power | 0,6 KW /12V |
| Hardened battery (standard) | 100 Ah / 12 V |
| Battery charger on board | 110 / 240 V -50/60 Hz |
| Lead acid battery | – |
| Gel battery | ● |
| Additional autonomy of battery | – |
| Proportional control on board of all mouvements | ● |
| Certification to standard 2006/42 CE | ● |
| Made in accordance (not certified) to standard UL508 A | – |
| Certification (issued by Third Party) to standard UL508 A | – |
| Drive hydraulic unit | – |
| Automatic braking system | – |
| Overloading safety system | ● |
| Pressure safety valves on each movements | ● |
| Safety emergency electric devices | ● |
| Winch (lifting capacity on demand) | – |
| Wireless remote control (capacity on demand) | – |
| User Manual and technical documentation | ● |
| Possibility to do all movements with max. Load | ● |
